One-Line Product Positioning
The S020 is a practical semi-smart toilet combining a heated seat, foam-shield splash and odor protection, foot-sensor operation, and automatic flushing for residential, hospitality, and commercial projects.
Product Overview
The DZOZO S020 integrates practical smart functions into a clean and compact one-piece design. It features a four-level heated seat, foam shield, foot-sensor operation, automatic flushing, night light, and backup flushing during a power outage.
Without a complex bidet washing and warm-air drying system, the S020 offers lower power consumption, simple operation, and easier maintenance. It is an ideal solution for customers who need essential smart toilet functions at a competitive cost.
The S020 supports 305 mm and 400 mm rough-in configurations, with pump-assisted and solenoid-valve flushing versions available. Voltage, plug type, functions, color, branding, manuals, and packaging can be customized for different markets.
Key Features
Four-Level Heated Seat
The heated seat provides OFF, low, medium, and high temperature settings for comfortable use in different seasons.
Foam-Shield Splash and Odor Protection
The foam shield covers the water surface to help reduce splashing, unpleasant odors, and waste adhesion inside the bowl.
Touch-Free Foot-Sensor Operation
The foot sensor can be configured for touch-free flushing, lid opening, and seat operation, reducing direct hand contact.
Automatic Flushing
The toilet can flush automatically after the user leaves the seat, improving hygiene and everyday convenience.
5L Siphonic Jet Flushing
The approximately 5.0 L siphonic jet flushing system delivers reliable waste removal while controlling water consumption.
Backup Flushing During Power Outages
A backup battery connection allows the flushing system to continue operating when the main power supply is unavailable.
305 mm and 400 mm Rough-In Options
The S020 supports both 305 mm and 400 mm rough-in configurations. Other rough-in requirements can be discussed for project orders.
Low-Power Semi-Smart Design
Rated power is approximately 50W or 115W, depending on the flushing configuration, making the S020 suitable for markets that do not require bidet washing or warm-air drying functions.
Technical Specifications
| Specification | Details |
|---|---|
| Model | S020 |
| Product Type | Integrated floor-standing semi-smart toilet |
| Overall Dimensions | 683 × 390 × 442 mm |
| Height with Lid Open | Approximately 937 mm |
| Standard Color | White |
| Optional Colors | Available subject to order quantity |
| Rough-In | 305 mm / 400 mm / other sizes subject to confirmation |
| Drainage Type | Floor outlet |
| Trap Type | S-trap |
| Outlet Diameter | ≤80 mm |
| Flushing System | Siphonic jet flushing |
| Flush Volume | Approximately 5.0 L |
| Water Pressure - Pump Version | 0.08-0.75 MPa |
| Water Pressure - Solenoid-Valve Version | 0.15-0.75 MPa |
| Rated Voltage | 110V/50Hz or 220V/60Hz, subject to order confirmation |
| Rated Power - Pump Version | Approximately 115W |
| Rated Power - Solenoid-Valve Version | Approximately 50W |
| Heated Seat Power | Approximately 50W |
| Seat Temperature Settings | OFF / Low / Medium / High |
| Waterproof Rating | IPX4 |
| Power Cord Length | Approximately 1.5 m |
| Plug Type | US / EU / UK / AU / customized plug |
| Operation | Side control knob and remote control |
| Foam Shield | Available depending on configuration |
| Foot-Sensor Flushing | Available depending on configuration |
| Foot-Sensor Lid/Seat Operation | Optional |
| Automatic Lid Opening | Optional |
| Automatic Flushing | Available depending on configuration |
| Bowl Pre-Wetting | Available depending on configuration |
| Night Light | Available |
| Power-Outage Flushing | Supported with backup battery |
| Safety Protection | Seat sensor, temperature sensor, thermostat and thermal fuse |
| Water and Energy Efficiency | Level 2 according to the instruction manual |
| Available Certification | CE |
| Bidet Washing | Not included in the standard S020 configuration |
| Warm-Air Drying |
Not included in the standard S020 configuration |
Safety and Comfort Features
- Seat occupancy sensor
- Temperature sensor
- Thermostat protection
- Thermal fuse protection
- Low-temperature burn protection
- Automatic seat temperature reduction after approximately 10 minutes
- Night light
- Automatic flushing
- Bowl pre-wetting, depending on configuration
- Foot-sensor flushing, depending on configuration
- Automatic lid opening, depending on configuration
- Backup flushing during a power outage
- Foam-shield splash and odor protection
Available Functions and Options
- Foam-shield system
- Foot-sensor flushing
- Foot-sensor lid opening
- Foot-sensor seat operation
- Automatic lid opening
- Automatic flushing after leaving the seat
- Automatic bowl pre-wetting
- Night light
- Backup battery flushing
- Pump-assisted flushing version
- Solenoid-valve flushing version
- 305 mm or 400 mm rough-in
- Customized voltage and frequency
- US, EU, UK, AU, or other plug types
- Customized product color
- Customized control panel and remote-control icons
- Customer logo and product nameplate
- Multilingual instruction manual
- Customized labels, barcode, carton, and packaging
OEM/ODM Customization
We support OEM and ODM customization for:
- Product functions and configuration
- Rough-in size
- Voltage and plug type
- Product color and decorative parts
- Customer logo and nameplate
- Remote-control design
- Instruction manual and language
- Product labels and barcodes
- Retail and export packaging
- Private-label production
Order Information
- Minimum order quantity: 1 unit
- Sample lead time: Approximately 10 days
- Mass production lead time: Approximately 30 days
- Available certification: CE
- Packaging: Kraft carton with reinforced wooden frame
- Warranty: Subject to order agreement and target market
- Spare parts support: Available
Replacement parts can include remote controls, control boards, foot-sensor modules, water inlet valves, pumps, foam bottles, and other service components.
